Plant 3D Engineering
2D/3D Plant Design
Techso Engineering delivers comprehensive 2D and 3D plant design services for industrial, oil & gas, energy, and process facilities, supporting clients from feasibility studies to detailed construction documentation.
Plant design is not only about modelling components — it is about integrating piping, structures, equipment, and utilities into a coordinated, constructible, and efficient system. Our multidisciplinary approach ensures technical consistency, clash-free layouts, and optimized installation solutions.
Full Project Lifecycle Support
We assist clients throughout all project phases:
- Conceptual layout and feasibility studies
- Basic engineering development
- Detailed engineering and shop drawings
- Construction documentation
- As-built documentation
Advanced 2D and 3D Modelling
We use industry-leading software platforms, including:
- AutoCAD
- Autodesk Inventor
- AVEVA E3D
- CADWorx
- Plant 3D
Through integrated 3D modelling, we develop:
- Complete piping layouts
- Equipment positioning and integration
- Pipe racks and supporting steel structures
- Utility routing (process, steam, fuel gas, utilities)
- Modular skid packages
Piping Engineering & Detailing
Our piping engineering services include:
- Piping layout development
- Line routing optimization
- Isometric drawings
- Bill of materials (BOM)
- Support specification and detailing
- Stress analysis coordination
We have extensive experience in high-temperature and heavy-duty applications, including refinery furnaces, burner supply lines, transfer lines, and decoking systems.
Particular attention is dedicated to constructability, maintenance access, and installation sequencing, ensuring that the design is not only compliant but also practical.
Modular Skid Engineering
In addition to conventional plant layouts, Techso Engineering develops modular skid packages integrating:
- Piping systems
- Structural frames
- Equipment
- Electrical and instrumentation systems
The modular approach allows:
- Reduced installation time
- Simplified transportation
- Improved quality control
- Lower commissioning risks
Each skid is engineered with full 3D coordination to guarantee mechanical integrity and operational efficiency.
Integration with Structural & Analysis Engineering
Our plant design activities are fully integrated with:
- Stress analysis (CAESAR II and other platforms)
- Structural verification of supports and frames
- Pipe support sizing and positioning
- Finite Element Analysis for critical components
This integrated workflow ensures that layouts are not only geometrically correct but also mechanically verified and code-compliant.
Codes and International Standards
Design activities are developed in accordance with international references such as:
- ASME B31.3 – Process Piping
- EN 13480 – Metallic Industrial Piping
- API standards
- Eurocodes
- ASCE standards
Our goal is to deliver engineering that combines technical precision, construction feasibility, and cost optimization.
Single Point of Responsibility
Techso Engineering acts as a single multidisciplinary partner, coordinating:
- Process requirements
- Piping design
- Structural integration
- Electrical and instrumentation interfaces
This approach reduces engineering interfaces, improves communication, and ensures consistency across all disciplines.
